Temperature Scanner PTC900A (8 Channel)

Get a Price/Quote

MOQ : 10 Pieces

Temperature Scanner PTC900A (8 Channel) Specification

Type
Temperature Scanner

Theory
Microprocessor Based

Capacity
8 Channel

Exterior Material
ABS Plastic or Sheet Metal Enclosure

External Size
Panel Mount, 96x96 mm (Standard DIN Size)

Controller System
Automatic Channel Scanning & Manual Selection

Temperature Range
-99.9C to 400.0C (Depends on Sensor)

Power Supply
230V AC, 50 Hz

Scan Rate
2 to 20 Seconds/Channel (Adjustable)

Accuracy
0.5% of F.S.

Display
4 Digit, 7 Segment LED for Temperature & Channel Indication

Mounting
Panel Mountable

Output
Relay Output (Optional) or Alarm Buzzer (Optional)

Weight
Approx. 0.5 kg

Resolution
0.1C / 1C (Selectable)

Input Sensors
RTD (Pt100) or Thermocouple (J/K type) selectable

Panel Cutout
92 x 92 mm

Sensor Fault Indication
Open Sensor Indication with Error Message

Operating Temperature
0C to 50C

Temperature Scanner PTC900A (8 Channel) Trade Information

Minimum Order Quantity
10 Pieces

Supply Ability
100 Pieces Per Week

Delivery Time
7 Days

About Temperature Scanner PTC900A (8 Channel)

To ensure the protection of power transformers, avail from us Temperature Scanner. Offered temperature scanners are used for the dry type transformers or oil filled transformers. Since these transformers work in high temperature conditions so it becomes important to supervise the temperature of transformer windings and transformer core. To ensure that provided temperature scanners are able to suit the above named application, we manufacture these temperature scanners by using high grade raw material.
