Transformer Monitoring System

Patrons can avail from us Transformer Monitoring System. Offered monitoring systems are widely appreciated as these are fitted with moisture monitoring sensors and are ideal for monitoring power and distribution transformers in the electric network. In addition to this, provided monitoring systems augment the reliability of the technical date such as current & voltage. These monitoring systems also present the information about moisture and oil temperature & level in the transformers.

Features:

• Large back light LCD( 21 I x 9) with 9 mm character size
• Measuring & statistical functions
• Data recording 8, event recorder with time stamp
• Fan & pump control of transformer
• 16 freely programmable binary inputs
• 12 binary outputs
• mA Input for oil & tap & mA output for oil, WTI & TAP
• Recording of hot spot temperature & life time consumption
• Direct resistance input for tap charger penmen indicator
• Limit value monitoring for all measurement quantiles
• PT100 is provided as direct input for OIL Temperature
• RS485 Modbus for recorded data evaluation
• Ethernet IEC 61850 IEC103 (Optional)
• Parallel operation having master/follower/independent options
• Auto/manual and local/remote control selections options
• Transform or cooler control & temperature alarms and trip facility
• Remote temperature indications for winding and top oil
• Recording of accumulated use of life of transformer
